50-60-75 W
Input Power :
50 / 60 / 75 W
Input Voltage Range :
100 – 277 V
Power Factor :
>=0.97
Input Current :
< 0.7 A
Total Harmonic Distortion (THD) :
<=10%
Frequency Range :
47-63 HZ
Driver :
DONE LED Driver
Driver Efficiency :
90%
Luminaire Efficacy :
120 ~ 130 Lm/W
LED Type -Efficiency :
Lumileds – 170 Lm/W
Output Lumen :
50 W – 6000 ~6500 Lm
60 W – 7200~7800 Lm
75W – 9000~9750 Lm
60 W – 7200~7800 Lm
75W – 9000~9750 Lm
Color Rendering Index (CRI) :
Ra>=80%
Color Temperature (CCT) :
3000 K – 4000 K - 5000 K – 6500 K
SDCM :
1-3 Steps
Beam Angle :
120° X 60°
Ambient Temperature&Humidity :
-5°C to 45°C
10% to 90%
10% to 90%
Protection :
Over Voltage Protection
Under Voltage Protection
Over Load Protection
Surge Protection 6 KV
Over Temperature Protection
Under Voltage Protection
Over Load Protection
Surge Protection 6 KV
Over Temperature Protection
Ingress of Protection :
IP66
Fixture Weight :
2.535 Kg
