200 W
Input Power :
200 W
Input Voltage Range :
100 – 277 V
Power Factor :
>=0.97
Input Current :
< 1 A
Total Harmonic Distortion (THD) :
<=10%
Frequency Range :
47-63 HZ
Driver :
DONE LED Driver
Driver Efficiency :
90%
Luminaire Efficacy :
120 ~ 130 Lm/W
LED Type -Efficiency :
Lumileds – 170 Lm/W
Output Lumen :
24000~26000 LM
Color Rendering Index (CRI) :
Ra>=80%
Color Temperature (CCT) :
3000 K - 4000 K – 5000 K – 6500 K
SDCM :
1-3 Steps
Beam Angle :
120° X 60°
Ambient Temperature&Humidity :
-5°C to 45°C
10% to 90%
10% to 90%
Protection :
Over Voltage Protection
Under Voltage Protection
Over Load Protection
Surge Protection 6 KV
Over Temperature Protection
Under Voltage Protection
Over Load Protection
Surge Protection 6 KV
Over Temperature Protection
Ingress of Protection :
IP66
Fixture Weight :
6.76 Kg
